Prozessor(en) |
Anzahl Prozessorkerne | 4 |
Anzahl der Rechenwerke | 12 |
Konfliktloser-Prozessor | Ja |
Prozessor(en) | x5-E3940 |
Prozessor Boost-Frequenz | 1,8 GHz |
Prozessor Cache Typ | L2 |
Prozessor Codename | Apollo Lake |
Prozessor Lithografie | 14 nm |
Prozessor-Cache | 2 MB |
Prozessor-Paketgröße | 24 x 31 mm |
Prozessor-Serien | Intel Atom x5 Series |
Prozessor-Taktfrequenz | 1,6 GHz |
Prozessor-Threads | 4 |
Prozessorbetriebsmodi | 64-Bit |
Prozessorfamilie | Intel Atom® |
Prozessorhersteller | Intel |
Tcase | 100 °C |
Thermal Design Power (TDP) | 9,5 W |
Thermal-Überwachungstechnologien | Ja |
Tjunction | 110 °C |
UART | Ja |
Speicher |
Interner Speichertyp | LPDDR4-SDRAM |
Speicherkapazität | 4 GB |
Bildschirm |
Art des Touchscreens | Kapazitiv |
Bildschirmdiagonale | 21,3 cm |
Display-Auflösung | 2560 x 1600 Pixel |
HD-Typ | 2K Ultra HD |
Helligkeit | 720 cd/m² |
Audio |
Anzahl eingebauter Lautsprecher | 2 |
Mikrofonanzahl | 2 |
Anschlüsse und Schnittstellen |
Anzahl HDMI-Anschlüsse | 0 |
USB 3.2 Gen 1 (3.1 Gen 1) Anzahl der Anschlüsse vom Typ C | 1 |
Gewicht und Abmessungen |
Breite | 228 mm |
Gewicht | 570 g |
Höhe | 150 mm |
Tiefe | 12,7 mm |
Betriebsbedingungen |
Betriebstemperatur | -20 - 50 °C |
Luftfeuchtigkeit bei Lagerung | 5 - 95 % |
Relative Luftfeuchtigkeit in Betrieb | 10 - 90 % |
Temperaturbereich bei Lagerung | -20 - 60 °C |
Netzwerk |
Bluetooth | Ja |
Bluetooth Low Energy (BLE) | Ja |
Bluetooth-Version | 4.2 |
Mobile Netzwerkverbindung | Nein |
Nahfeldkommunikation (NFC) | Ja |
Top WLAN-Standard | Wi-Fi 5 (802.11ac) |
WLAN-Standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
Speichermedium |
Integrierter Kartenleser | Ja |
Interne Speicherkapazität | 64 GB |
Kompatible Speicherkarten | MMC |
Speichermedien | eMMC |
Kamera |
Auflösung Frontkamera (numerisch) | 2 MP |
Auflösung Rückkamera (numerisch) | 8 MP |
Autofokus | Ja |
Front Kamera | Ja |
Maximale Video-Auflösung | 1920 x 1080 Pixel |
Rückkamera-Blitz | Ja |
Rückkamera-Typ | Einzelne Kamera |
Video-Capture Geschwindigkeit | 30 fps |
Videoaufnahme | Ja |
Videoaufnahme-Modi | 1080p |
Sonstige Funktionen |
ARK Prozessorerkennung | 96485 |
Akku/Batterie |
Akku-/Batteriekapazität | 3300 mAh |
Akku-/Batteriespannung | 7,6 V |
Akku-/Batterietechnologie | Lithium |
Batteriekapazität | 25 Wh |
Prozessor Besonderheiten |
Eingebettete Optionen verfügbar | Ja |
Execute Disable Bit | Ja |
Intel HD-Audio-Technik | Ja |
Intel Stable Image Platform Program (SIPP) | Nein |
Intel® 64 | Ja |
Intel® AES New Instructions (Intel® AES-NI) | Ja |
Intel® Anti-Theft Technologie (Intel® AT) | Nein |
Intel® Clear Video HD Technology für (Intel® CVT HD) | Ja |
Intel® Clear Video Technologie | Ja |
Intel® Hyper-Threading-Technik (Intel® HT Technology) | Nein |
Intel® Identity-Protection-Technologie (Intel® IPT) | Ja |
Intel® OS Guard | Nein |
Intel® Quick-Sync-Video-Technik | Ja |
Intel® Rapid-Storage-Technik | Nein |
Intel® Secure Boot | Ja |
Intel® Sicherer Schlüssel | Ja |
Intel® Smart-Connect-Technik | Nein |
Intel® Smart-Response-Technologie | Nein |
Intel® Trusted-Execution-Technik | Nein |
Intel® Turbo-Boost-Technologie | Nein |
Intel® VT-x mit Extended Page Tables (EPT) | Ja |
Intel® Virtualisierungstechnik für direkte I/O (VT-d) | Ja |
Intel® Virtualization Technologie (VT-X) | Ja |
Leerlauf Zustände | Ja |
Physical Address Extension (PAE) | 40 Bit |
Physical Address Extension (PAE) | 40 Bit |
Verbesserte Intel SpeedStep Technologie | Ja |
Design |
Formfaktor | Tablet |
Gerätetyp | Mobiles Tablet |
Internationale Schutzart (IP-Code) | IP65 |
MIL-STD-810G-konform | Ja |
Produktfarbe | Schwarz |
Robustes Design | Ja |
Leistungen |
Beschleunigungsmesser | Ja |
Elektronischer Kompass | Ja |
GLONASS | Ja |
GPS | Ja |
Galileo | Ja |
Gyroskop | Ja |
Orientierungssensor | Ja |
Standort-Position | Ja |
Umgebungslichtsensor | Ja |
Software |
Installiertes Betriebssystem | Windows 10 IoT Enterprise |
Plattform | Windows |
Logistikdaten |
Warentarifnummer (HS) | 84713000 |
